USN - Lockheed R7V-2 Super Constellation BuNo

United states Navy - Lockheed R7V-2 Super Constellation BuNo 131630 or 131631. Turbo-Prop conversion of the R7V-1 for the US Navy. In November 1951, an idea came about to build a turbine-powered version of the R7O-1. This new aircraft was designated L-1249A by Lockheed. In 1954, two R7O-1s (then designated R7V-1) were pulled off the assembly line for conversion into prototypes for the new L-1249A. The landing gear was strengthened along with the fuselage and wings of the aircraft. Extra fuel tanks were also later added on the wing-tips of the two aircraft, increasing the fuel capacity to 7,360 US Gallons. The wings were also shortened from 123 ft 9 in to 117 ft 7 in. Finally, four Pratt & Whitney YT34-P-12A turboprop engines, rated at 5,500 bhp each, were installed in place of the usual Wright R-3350 Duplex-Cyclone radial engines. The new aircraft was designated R7V-2, and first flew on 1 September 1954. The R7V-2 reached 412 mph making it the fastest transport aircraft in the world at the time. The two R7V-2 aircraft were delivered to the Navy on 10 September the same year. Date: circa 1951

© The Peter Butt Aviation Collection / Mary Evans

Pregnant Guppy N1024V under construction

Pregnant Guppy N1024V under construction with On Mark Engineering at LAX - March 1962. the conversion was carried out in stages, First a portion of BOAC Stratocruiser was inserted in the rear fuselage and then the large outer shell of the cargo compartment was added to the standard B337 fuselage, for aerodynamic and structural trials. After the aircraft flew successfully and was demonstrated to Wernher von Braun, sufficient interest was generated to complete the conversion by cutting away the standard fuselage inside the large shell. - (photographer - AR Krieger) Date: 1962

© The Peter Butt Aviation Collection / Mary Evans

Containers for transporting & storing plants & seeds

Containers for transporting & storing plants & seeds. Illustration from John Ellis, Directions for bringing over seeds and plants from the East Indies to which is added, The figure and botanical description of a new sensitive plant, called Dioneaea muscipula, or Venus's fly-trap Date: 1770

© The John Innes Centre/The John Innes Foundation/Mary Evans

1770, Added, Botanical, Bringing, Called, Containers, Description, Dioneaea, Directions, East, Ellis, Figure, Fly, Illustration, Indies, John, Muscipula, New, Plant, Plants, Seeds, Sensitive, Storing, Transporting, Venuss
